Intermediate-frequency Inverse DC Spot (Projection) Welding Machine

Intermediate-frequency Inverse DC Spot (Projection) Welding Machine


Model:DTB-80/DTB-160/DTB240
Price:DTB-80 59800-79800 RMB9250-12350 USD
Price:DTB-160 12350-99800 RMB≈12350-15420 USD
Price:DTB-240 119800-139800 RMB≈18500-21600 USD
Factory:DongGuan,GuangDong,China
welding sample for free  Chat Now
It is especially suitable for the welding of aluminum, copper, galvanized sheet, carbon steel, nickel, tungsten and other metal materials, high temperature enamelled wire, soft connection and inductance coil. It is widely used in the welding of metal products in the fields of automobile and auto parts manufacturing, new energy power battery, photoelectric communication, electric light source, compressor, hardware, furniture, Kitchenware and so on.

  • Spot Welding Machine Videos
  • Laser Welding Machine Videos
  • Welding Machine Videos
  • Welding Videos


Product highlights: energy saving, power saving, high efficiency, low operation cost and high welding quality. Product overview: the medium frequency inverter DC spot welding machine converts the power frequency (50Hz) AC to the medium frequency (1000Hz) DC output. The time resolution is higher than that of the power frequency, the control accuracy is also improved, and the output current is not affected by the change of the secondary output circuit. It has high thermal efficiency, large output power rate and better welding quality. Compared with the traditional power frequency welding machine, inverter medium frequency DC welding will be efficient and energy-saving. It is a technological revolution breakthrough in the field of resistance welding.

  • 01

    The output current is DC, the current is smooth, and the inductive reactance is zero. The working frequency is 1000Hz, and the time control accuracy is 1ms.

  • 02

    The fuselage adopts steel plate mechanical structure design, which is beautiful and rigid, so as to ensure stable welding quality.

  • 03

    The electrode voltage mechanism is integrated, the gas circuit is short, the structure is compact, the reaction speed is faster, and the installation and maintenance are more convenient.

  • 04

    The secondary circuit adopts high-quality conductive materials, which greatly reduces the circuit impedance.

  • 05

    The cylinder reversing valve adopts imported brand, with fast response speed, large flow and long service life, which meets the requirements of high-speed management.

  • 06

    The standard components are brand, so that the overall quality of the welding machine can reach the standard.

  • 07

    Equipped with medium frequency welding controller and current closed-loop control, it can control the actual welding current at high speed.

  • 08

    Large LCD screen interface with Chinese and English switching display.

  • 09

    High quality and high efficiency welding capacity, power factor up to 98%, three-phase input load balance, greatly reducing the impact on the user's power grid.

parameter DTB-80 DTB-160 DTB-240
Rated capacity 80KVA 160KVA 240KVA
Input power three φ 380V three φ 380V three φ 380V
Maximum short circuit current 25KA 35KA 50KA
Load duration 20% 20% 20%
control mode Primary / secondary constant current Primary / secondary constant current Primary / secondary constant current
Inverter frequency 1000HZ 1000HZ 1000HZ
Maximum pressure 6000N 6000N 12000N
Electrode stroke 60mm 60mm 100mm
Cooling water flow 12L/min 12L/min 14L/min
Welding capacity / aluminum plate 2.0+2.0mm 2.5+2.5 mm 3.0+3.0 mm
Welding capacity / carbon steel 2.5+2.5mm 3.0+3.0 mm 4.0+4.0 mm
Arm extension size five hundred × 250mm five hundred × 250mm five hundred × 350mm
Electrode arm size ¢59 × 173mm ¢59 × 173mm ¢74 × 195mm
Electrode holder size ¢24.6 × 180 mm ¢24.6 × 180 mm ¢31.6 × 250 mm
Electrode head size ¢16 × 50 mm ¢16 × 50 mm ¢20 × 60 mm
weight 350kg 400kg 750kg
Overall dimension 1100×700×1730mm 1100×700×1730mm 1205×870×2140mm
